2023 Scrambler 1200 XE
2023 Triumph Scrambler 1200 XC For Sale Richmond
Review 2023 Triumph Scrambler 1200 XC Specifications, Features & Colours Available at Virtual Triumph
Book a Test Ride
Schedule your Triumph test ride today at Virtual Triumph.
Available Colours
Sapphire Black
Get a Quote
Virtual Triumph – where your quote is just a click away.
Key Highlights
1200 CC ENGINE
Updated for Euro 5 compliance, with enhanced emissions and a dedicated Scrambler tune, for a smooth, torque-rich delivery from the iconic 1200cc Bonneville twin.
ENHANCED TWIN HIGH LEVEL EXHAUST
The deep, Scrambler tone from the signature twin high-level exhaust now features for 2021 improved heat distribution for enhanced rider comfort.
RIDING MODES
In addition to the Road, Rain, Sport, Off-Road and Rider-Configurable riding modes, the XE features ‘Off-Road Pro’ for full on Scrambler fun.
FULL COLOUR TFT
Easy to read in all light conditions, the Scrambler’s advanced full-colour TFT display can be configured to suit you and your riding needs.
ILLUMINATED SWITCHES
Intuitively designed, the Scrambler’s switches are backlit for easy, at-a-glance rider control, perfect for even the darkest adventures.
SPECIFICATION & CAPABILITY
The Scrambler’s category-dominating specification and high-end equipment deliver all-road capability for an adventure riding experience like no other.
DEDICATED SCRAMBLER FRAME
The dedicated frame and long travel aluminium swinging arm are designed for pure Scrambler performance when the going gets tough.
OPTIMISED CORNERING
Optimised cornering traction control and ABS, supported by an IMU, deliver the optimum performance at all lean angles, for a class-leading and confidence-inspiring ride.
CLASS-LEADING SUSPENSION
Premium Showa forks and twin spring Öhlins RSUs give 250mm of wheel travel for precise, comfortable and confident riding on all surfaces.
PREMIUM BRAKING
Category-leading Brembo Monobloc M50 front calipers with twin 320mm floating discs and ABS deliver assured braking power in all conditions.
Request a Brochure
Discover the model — request your brochure today at Virtual Triumph!
Technical Data
Type
Liquid-cooled, parallel twin, 8 valve, SOHC, 270° firing order
Capacity
1200 cc
Bore
97.6 mm
Stroke
80 mm mm
Compression
11:1
Max power
90 PS / 89 bhp (66.2 kW) @ 7,300 rpm
Max Torque
110 Nm @ 4,500 rpm
System
Multipoint, sequential electronic fuel injection with electronic throttle control
Exhaust
Single skin, brushed 2-into-1 exhaust system with high-level silencer
Final drive
O-Ring Chain
Clutch
Wet, multi-plate assist
Gearbox
6 speed
Frame
Tubular steel, steel cradles
Swingarm
Twin-sided, fabricated aluminium
Front wheel
Spoked, Aluminium rimmed 36 spoke 2.15 x 21 in
Rear wheel
Spoked wheel with aluminium rim, 32-spoke, 17 x 4.25 in
Front tyre
90/90-21
Rear tyre
150/70 R17
Front suspension
Showa 47 mm upside-down BP-SFF forks, preload adjustment, compression and rebound damping. 250 mm wheel travel
Rear suspension
Öhlins twin (RSU) with piggy-back reservoirs and twin springs, preload adjustment, compression and rebound damping. 250 mm wheel travel
Front brakes
Twin 320 mm discs, Brembo 4-piston M4.30 radial monoblock calipers, OCABS
Rear brakes
Single, 255 mm disc, Nissin single-piston floating caliper, OCABS
Instruments
Multi-function instruments with colour TFT screen
Width
905 mm
Height
1250 mm
Seat height
870 mm
Wheel base
1570 mm
Rake
26.9 °
Trail
129 mm
Wet weight
230 kg
Fuel capacity
15 l
