2024 TF 250-X
2024 Triumph TF 250-X For Sale Richmond
Review 2024 Triumph TF 250-X Specifications, Features & Colours Available at Virtual Triumph
Book a Test Ride
Schedule your Triumph test ride today at Virtual Triumph.
Available Colours
Triumph Racing Yellow / Black / White
Get a Quote
Virtual Triumph – where your quote is just a click away.
Key Highlights
FOCUSED PERFORMANCE
Exploiting Triumph's dominant position in motorcycle performance and capability - The all-new Triumph 250cc single powertrain marks a significant shift in the world of motocross.
POWER DELIVERED
Get ready for a fully dialled-in riding experience. The TF 250-X generates smooth and controllable power that quickly builds up throughout the entire rev range.
PERFORMANCE MANAGEMENT
A vented airbox cover allows for optimal airflow, and the air filter can be changed without tools in seconds.
STRENGTH & FLEXIBILITY
The central spine with twin cradle design is unique to Triumph. The brushed aluminium frame has incredible strength and flexibility for the most punishing conditions.
AGILITY AND CONTROL
The TF 250-X is designed to achieve the perfect balance of mass, performance, and flexibility. The chassis combines world-class precision and agility to deliver a winning performance at the highest level.
PREMIUM SPECIFICATION
The TF 250-X boasts class-leading specification and includes the most wanted features in MX racing.
Request a Brochure
Discover the model — request your brochure today at Virtual Triumph!
Technical Data
Type
Single Cylinder 4-Stroke DOHC
Capacity
249.95 cc
Bore
78 mm
Stroke
52.3 mm
Compression
14.4
System
Dellorto Throttle Body, Athena EMS
Exhaust
Single Silencer
Final Drive
13/48
Clutch
Wet Multi-Plate Belleville Spring
Gearbox
5 Speed
Frame
Aluminium, Spine & Double Cradle
Swingarm
Aluminium Fabrication
Front Wheel
21" x 1.6"
Rear Wheel
19" x 1.85"
Front Tyre
80/100 - 21
Rear Tyre
100/90 - 19
Front Suspension
KYB 48mm Coil Spring Fork, Compression/Rebound Adjustment, 310mm Travel
Rear Suspension
KYB Coil, Compression Adjustment (H and L Speed), Rebound Adjustment, 305mm Travel
Front Brakes
Brembo Twin 24mm Piston, 260mm Disc
Rear Brakes
Brembo Single 26mm Piston, 220mm Disc
Instrument Display and Functions
Hour Meter, Multifunction Switch Cubes
Width Handlebars
836 mm
Height Without Mirror
1270 mm
Seat Height
960 mm
Wheelbase
1492 mm
Rake
27.4 º
Trail
116 mm
Tank Capacity
7 L
Wet Weight
104 kg
